NDP1450KC is a high efficiency, monolithic synchronous step-down DC/DC converter utilizing a constant frequency, average current mode control architecture. Capable of delivering up to 5A continuous load with excellent line and load regulation. The device operates from an input voltage range of 7V to 38V and provides an adjustable output voltage from 3.3V to 25V.
    The NDP1450KC features short circuit and thermal protection circuits to increase system reliability. The internal soft-start avoids input inrush current during startup.
    The NDP1450KC require a minimum number of external components. and a wide array of protection features to enhance reliability.

※Wide VIN Range : 7V to 38V
※5A Continuous Output Current
※Up to 95% Efficiency @ 24V Input
※Dual-Channel CC/CV Mode Control
※Brick Wall Current Limit
※Built in Adjustable Line-Compensation
※Adjustable Output Voltages
※+/-1.5% Output Voltage Accuracy
※+/- 5% Current Limit Accuracy
※Integrated 14mΩ High Side Switch
※Integrated 14mΩ Low Side Switch
※Fixed 130KHz Frequency
※Burst Mode Operation at Light Load
※Internal loop Compensation
※Internal Soft Start
※Available in SOP8 Package

※Car Charger
※Rchargeable Portable Devices
※Networking Systems
※Distributed Power Systems
