NDP1331KC is a high efficiency, monolithic synchronous step-down DC/DC converter utilizing a constant frequency, average current mode control architecture.  Capable of delivering up to 2.8A continuous load with excellent line and load regulation. The device operates from an input voltage range of 7V to 32V and provides an adjustable output voltage from 3.6V to 25V.
     The NDP1331KC features short circuit and thermal protection circuits to increase system reliability. The internal soft-start avoids input inrush current during startup.
     The NDP1331KC require a minimum number of external components. and a wide array of protection features to enhance reliability.

※ Wide VIN Range : 7V to 32V

※ 2.8A Continuous Output Current

※ Up to 93% Efficiency

※ CC/CV Mode Control

※ Built in Adjustable Line-Compensation

※ Adjustable Output Voltages

※ +/-1.5% Output Voltage Accuracy

※ +/- 5% Current Limit Accuracy

※ Integrated 75mΩ High Side Switch

※ Integrated 35mΩ Low Side Switch

※ Programable Frequency(130KHz~300KHz)

※ Burst Mode Operation at Light Load

※ Internal loop Compensation

※ Internal Soft Start

※ Car Charger

※ Rechargeable Portable Devices

※ Networking Systems

※ Distributed Power Systems
