NDP13802QB is a high efficiency, monolithic synchronous step-down DC/DC converter utilizing a Jitter frequency, average current mode control architecture. Capable of delivering up to 8A continuous load with excellent line and load regulation. The device operates from an input voltage range of 7V to 30V and provides an adjustable output voltage from 3.3V to 25V.
The NDP13802QB features short circuit and thermal protection circuits to increase system reliability. The internal soft-start avoids input inrush current during startup.
The NDP13802QB require a minimum number of external components. and a wide array of protection features to enhance reliability.
l Wide VIN Range :7V to 30V
l 8A Continuous Output Current
l Up to 95% Efficiency @ 24V Input
l Dual-Channel CC/CV Mode Control
l Brick Wall Current Limit
l Built in Adjustable Line-Compensation
l Adjustable Output Voltages
l +/-1.5% Output Voltage Accuracy
l +- 5% Current Limit Accuracy.
l Integrated 8mΩ High Side Switch
l Integrated 8mΩ Low Side Switch
l Programable Frequency(130KHz~300KHz)
l Burst Mode Operation at Light Load
l Internal loop Compensation
l Internal Soft Start
l Thermally Enhanced QFN5*5 Package
l Car Charger
l Rechargeable Portable Devices
l Networking Systems
l Distributed Power Systems
